Portable Dissolved Oxygen Meter

- Technical Specifications Model HI 9146-04

Measurement range
oxygen content mg / l from 0,00 to 45,00
saturation % from 0,0 to 300,0
temperature ºC from 0,0 to 50,0

Resolution
oxygen content mg / l 0,01
saturation % 0,1 %
temperature ºC 0,1 °C

Accuracy
oxygen content mg / l ± 1.5% of full scale
saturation % ± 1.5% of full scale
temperature ºC ± 0.2 ° C (excluding probe error)

- Calibration: automatic, in the air at 100%
- Temperature compensation: automatic
- Salt compensation: 0 ... 80 g/l with 1 g/l resolution
- Altitude compensation: 0 ... 4000 m with 100 m resoltion
- HI 9146-10: 10 meter wire
- Battery : 3 AAA batteries 1.5 V / 200 h approx. duration
- Environmental conditions: maximum 50 °C, maximum 95 % R.H.
- Dimensions: 185 x 72 x 36 mm
- Weight: 300 g
