Lit Fluidisant de Laboratoire, Modèle DL-410, Yamato

*** NEW MODEL, REPLACES DL-41 ***

- The specs of the DL-410 are the same as DL-41, the only
difference is that the DL-410 has a new touch control panel.

- new touch panel control
- water evaporation rate : max 3000 ml/h
- wpraying system : 2-liquid nozzle system (dia. of orifice : 0.7 mm)
- spray/hot air contact system : downward spray parallel flow system
- sample liquid feed pump : quantitative peristaltic pump
flow rate variable up to 80 ml/h
- aspirator : bypass-type commutator blower, air flow rate variable up to 1m³/min
- heating system with control : 0°C to 300°C
- heating exit with control : 0°C to 200°C
- pressure : 0 to 0.4 MPa
- spray nozzle : co ncentration aroung 20 g/l
- recuperation system for powder
- drying chamber dimensions : 450 dia x 1000 mm (glass part)
- external dimensions : 1 060 W x 880 D x 1 750 H (mm)
- 120 / 220 volts
WARRANTY : 12 months on parts and labor
