Darkroom Viewing Cabinet

- Analtech Darkroom Viewing Cabinet has two overhead ports which accept one or
two 8 watt combination short/long wave portable UV lamps
- These 8 watt lamps offer typical light intensities at the cabinet floor of 470 W/cm2
at 365 nm and 650 W/cm2 at 254 nm
- Centered between the lamp ports is an integrally UV filtered viewing port with a
plastic eye shield Illumination in the visible spectrum is provided by an internal
white light source
- The cabinet is of sturdy metal construction with a polyurethane coating for
chemical resistance
- A 5 x 15 inch entry port allows access to a flat viewing surface large enough to
accommodate two 20 x 20 cm TLC plates
- A weighted, dark felt curtain covers the opening and insures a light-tight
viewing area
- Available in 110V or 230V.
- With the Analtech Photodocumentation System, accurate records of your TLC or
gel separations are easy to make
